View In:   ArcGIS Online Map Viewer

Name: All_Roads

Display Field: RouteId

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The LRSN_AllRoads feature class is an Esri Roads and Highways Network (or more generically a Linear Referencing Method) that represents all public roads in California, including state highways.LRSN_AllRoads serves as the state's All Roads Network of Linear Referenced Data (ARNOLD) and meets this Federal Highways Administration (FHWA) requirement.Additionally, LRSN_AllRoads is the Linear Referencing Method that supports the majority of business data that are not necessarily referenced to the Caltrans Postmile System (in other words, these data can be on roads that are not part of the state highway system). This currently includes all of the Highway Performance Monitoring System (HPMS).Each route is fully represented by a Primary alignment; any divided routes have an additional Secondary alignment for those divided sections. State highways always have full Secondary alignments.

Service Item Id: 93d1cf08155c4999893318ea33025ec8

Copyright Text: California Department of Transportation (Caltrans)

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -1.38488617581E7
YMin: 3833714.521399997
XMax: -1.2705439114E7
YMax: 5162299.121799998
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 92, 230, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• RouteId ( type: esriFieldTypeString, alias: RouteId, editable: true, nullable: true, length: 75, defaultValue: null, modelName: RouteId )
• LRSFromDate ( type: esriFieldTypeDate, alias: LRSFromDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LRSFromDate )
• LRSToDate ( type: esriFieldTypeDate, alias: LRSToDate, editable: true, nullable: true, length: 8, defaultValue: null, modelName: LRSToDate )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: true, defaultValue: null, modelName: Shape.STLength() )

Templates:

• Name: All_Roads
  Description:
  Prototype:
  LRSFromDate: null
  LRSToDate: null
  RouteId: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
