Name: State Highway Network Postmiles

Display Field: RteSuffix

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: StateHighways are state highways based upon the Caltrans Linear Referencing System. Each record in this layer represents a highway segment where the county, route, postmile prefix, and postmile suffix are the same. Each segment has a begin and end postmile. This geometry is based upon the extraction from TSN on 10 October 2022.

Service Item Id: c0d1ebfca02c43efbd19bb100796d10d

Copyright Text: California Department of Transportation (Caltrans)

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -401129.8149902244
YMin: -607491.2809005156
XMax: 536129.2033815057
YMax: 457262.3579476187
Spatial Reference: 102962  (6414)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 92, 230, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Route ( type: esriFieldTypeSmallInteger, alias: Route )
• RteSuffix ( type: esriFieldTypeString, alias: RteSuffix, length: 1 )
• RouteS ( type: esriFieldTypeString, alias: RouteS, length: 4 )
• PMRouteID ( type: esriFieldTypeString, alias: PMRouteID, length: 10 )
• County ( type: esriFieldTypeString, alias: County, length: 3 )
• District ( type: esriFieldTypeSmallInteger, alias: District )
• PMPrefix ( type: esriFieldTypeString, alias: PMPrefix, length: 1 )
• bPM ( type: esriFieldTypeDouble, alias: bPM )
• ePM ( type: esriFieldTypeDouble, alias: ePM )
• PMSuffix ( type: esriFieldTypeString, alias: PMSuffix, length: 1 )
• bPMc ( type: esriFieldTypeString, alias: bPMc, length: 9 )
• ePMc ( type: esriFieldTypeString, alias: ePMc, length: 9 )
• bOdometer ( type: esriFieldTypeDouble, alias: bOdometer )
• eOdometer ( type: esriFieldTypeDouble, alias: eOdometer )
• AlignCode ( type: esriFieldTypeString, alias: AlignCode, length: 20 )
• RouteType ( type: esriFieldTypeString, alias: RouteType, length: 10 )
• Direction ( type: esriFieldTypeString, alias: Direction, length: 2 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
