Name: State Highway System Intersection

Display Field: Major_StreetName

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: As part of the Transportation System Network Replacement Project (TSNR), Highway Inventory module data migration, it was determined Caltrans would be utilizing Rizing’s Intersection Manager (IM) product to create and manage intersection data. Because Caltrans is using Roads and Highways (R&H) and maintains the AllRoads and Postmile networks together in R&H, the system provides translation tools to derive the Postmile value at the intersection points using the AllRoads LRS information. Methodology - The source of data is a combination of Caltrans Roads and Highways (R&H), the AllRoads and Postmile networks together in R&H. This is implemented by creating a process to populate the Postmile values onto the DOT-maintained Intersection detailed dataset.

Service Item Id: d917209fe3f14bd697d91d5a68b758db

Copyright Text: California Department of Transportation (Caltrans)

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.38329940777E7
YMin: 3837629.5352
XMax: -1.27239169574E7
YMax: 5161179.4706000015
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [0, 92, 230, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Master_Intersection_ID ( type: esriFieldTypeString, alias: Master_Intersection_ID, length: 255 )
• Date_Of_Record ( type: esriFieldTypeDate, alias: Date_Of_Record, length: 8 )
• Intersection_Geometry ( type: esriFieldTypeString, alias: Intersection_Geometry, length: 2 , Coded Values: [F: F- Four-Legged] , [M: M- Multi-Legged] , [S: S- Offset] , ...6 more... )
• Intersection_Geometry_Eff_Date ( type: esriFieldTypeDate, alias: Intersection_Geometry_Eff_Date, length: 8 )
• Intersection_Control ( type: esriFieldTypeString, alias: Intersection_Control, length: 1 , Coded Values: [A: A- No Control] , [B: B- Stop Signs on Cross Street Only] , [C: C- Stop Signs on Mainline Only] , ...11 more... )
• Intersection_Control_Eff_Date ( type: esriFieldTypeDate, alias: Intersection_Control_Eff_Date, length: 8 )
• Intersection_Lighted_Ind ( type: esriFieldTypeSmallInteger, alias: Intersection_Lighted_Ind , Coded Values: [0: 0 - No] , [1: 1 - Yes] )
• Intersection_Lighted_Eff_Date ( type: esriFieldTypeDate, alias: Intersection_Lighted_Eff_Date, length: 8 )
• Description ( type: esriFieldTypeString, alias: Description, length: 200 )
• Number_Approaches ( type: esriFieldTypeDouble, alias: Number_Approaches )
• Number_Legs ( type: esriFieldTypeSmallInteger, alias: Number_Legs )
• Ramp_Terminal_Ind ( type: esriFieldTypeInteger, alias: Ramp_Terminal_Ind )
• Approach_Effective_Date ( type: esriFieldTypeDate, alias: Approach_Effective_Date, length: 8 )
• Major_ARRouteID ( type: esriFieldTypeString, alias: Major_ARRouteID, length: 75 )
• Major_ARMeasure ( type: esriFieldTypeDouble, alias: Major_ARMeasure )
• Major_StreetName ( type: esriFieldTypeString, alias: Major_StreetName, length: 150 )
• Major_District ( type: esriFieldTypeString, alias: Major_District, length: 3 )
• Major_County ( type: esriFieldTypeString, alias: Major_County, length: 3 , Coded Values: [SHA: Shasta] , [SIE: Sierra] , [SIS: Siskiyou] , ...55 more... )
• Major_City ( type: esriFieldTypeString, alias: Major_City, length: 6 , Coded Values: [ADA: ARCADIA] , [ADEL: ADELANTO] , [AGRH: AGOURA HILLS] , ...551 more... )
• Major_FlowCode ( type: esriFieldTypeString, alias: Major_FlowCode, length: 2 , Coded Values: [N: N- Two-Way Traffic – No Left Turns Permitted] , [P: P- Two-Way Traffic – Left Turns Permitted] , [R: R- Two-way-Traffic – Left Turns Restrict for Pk Hrs] , ...2 more... )
• Major_Pri_Num_Lanes ( type: esriFieldTypeInteger, alias: Major_Pri_Num_Lanes )
• Major_Sec_Num_Lanes ( type: esriFieldTypeInteger, alias: Major_Sec_Num_Lanes )
• Major_Total_Num_Lanes ( type: esriFieldTypeInteger, alias: Major_Total_Num_Lanes )
• Major_Ownership ( type: esriFieldTypeSmallInteger, alias: Major_Ownership , Coded Values: [1: State Highway Agency] , [2: County Highway Agency] , [3: Town or Township Highway Agency] , ...24 more... )
• Major_Functional_Class ( type: esriFieldTypeSmallInteger, alias: Major_Functional_Class , Coded Values: [1: 1 - Interstate] , [2: 2 - Principal Arterial - Other Freeways and Expressways] , [3: 3 - Principal Arterial - Other] , ...4 more... )
• Major_Population_Code ( type: esriFieldTypeString, alias: Major_Population_Code, length: 1 , Coded Values: [B: B - Urbanized] , [R: R - Rural] , [U: U - Urbanized] )
• Major_Max_AADT ( type: esriFieldTypeInteger, alias: Major_Max_AADT )
• Major_Avg_AADT ( type: esriFieldTypeInteger, alias: Major_Avg_AADT )
• Major_AADT_YEAR ( type: esriFieldTypeString, alias: Major_AADT_YEAR, length: 4 )
• Major_Highway_Group ( type: esriFieldTypeString, alias: Major_Highway_Group, length: 1 , Coded Values: [D: D - Divided Highway] , [L: L - Independent Alignment - Left] , [R: R - Independent Alignment - Right] , ...2 more... )
• Major_Signal_Arm_Ind ( type: esriFieldTypeSmallInteger, alias: Major_Signal_Arm_Ind , Coded Values: [0: 0 - No] , [1: 1 - Yes] )
• Major_Left_Channel ( type: esriFieldTypeString, alias: Major_Left_Channel, length: 1 , Coded Values: [C: C- Curbed Median Left Turn Channelization] , [N: N- No Left Turn Channelization] , [P: P- Painted Left Turn Channelization] , ...2 more... )
• Major_Right_Channel_Ind ( type: esriFieldTypeString, alias: Major_Right_Channel_Ind, length: 1 )
• Major_N_Distance ( type: esriFieldTypeInteger, alias: Major_N_Distance )
• Major_PMRouteID ( type: esriFieldTypeString, alias: Major_PMRouteID, length: 75 )
• Major_RouteNum ( type: esriFieldTypeString, alias: Major_RouteNum, length: 4 )
• Major_RouteSuffix ( type: esriFieldTypeString, alias: Major_RouteSuffix, length: 1 )
• Major_Alignment ( type: esriFieldTypeString, alias: Major_Alignment, length: 1 )
• Major_PMPrefix ( type: esriFieldTypeString, alias: Major_PMPrefix, length: 1 )
• Major_PMSuffix ( type: esriFieldTypeString, alias: Major_PMSuffix, length: 1 )
• Major_PMMeasure ( type: esriFieldTypeDouble, alias: Major_PMMeasure )
• Minor_ARRouteID ( type: esriFieldTypeString, alias: Minor_ARRouteID, length: 75 )
• Minor_ARMeasure ( type: esriFieldTypeDouble, alias: Minor_ARMeasure )
• Minor_StreetName ( type: esriFieldTypeString, alias: Minor_StreetName, length: 150 )
• Minor_County ( type: esriFieldTypeString, alias: Minor_County, length: 3 , Coded Values: [SHA: Shasta] , [SIE: Sierra] , [SIS: Siskiyou] , ...55 more... )
• Minor_City ( type: esriFieldTypeString, alias: Minor_City, length: 6 , Coded Values: [ADA: ARCADIA] , [ADEL: ADELANTO] , [AGRH: AGOURA HILLS] , ...551 more... )
• Minor_FlowCode ( type: esriFieldTypeString, alias: Minor_FlowCode, length: 2 , Coded Values: [N: N- Two-Way Traffic – No Left Turns Permitted] , [P: P- Two-Way Traffic – Left Turns Permitted] , [R: R- Two-way-Traffic – Left Turns Restrict for Pk Hrs] , ...2 more... )
• Minor_Pri_Num_Lanes ( type: esriFieldTypeInteger, alias: Minor_Pri_Num_Lanes )
• Minor_Sec_Num_Lanes ( type: esriFieldTypeInteger, alias: Minor_Sec_Num_Lanes )
• Minor_Total_Num_Lanes ( type: esriFieldTypeInteger, alias: Minor_Total_Num_Lanes )
• Minor_Ownership ( type: esriFieldTypeSmallInteger, alias: Minor_Ownership , Coded Values: [1: State Highway Agency] , [2: County Highway Agency] , [3: Town or Township Highway Agency] , ...24 more... )
• Minor_Functional_Class ( type: esriFieldTypeSmallInteger, alias: Minor_Functional_Class , Coded Values: [1: 1 - Interstate] , [2: 2 - Principal Arterial - Other Freeways and Expressways] , [3: 3 - Principal Arterial - Other] , ...4 more... )
• Minor_Population_Code ( type: esriFieldTypeString, alias: Minor_Population_Code, length: 1 , Coded Values: [B: B - Urbanized] , [R: R - Rural] , [U: U - Urbanized] )
• Minor_AADT ( type: esriFieldTypeInteger, alias: Minor_AADT )
• Minor_AADT_YEAR ( type: esriFieldTypeString, alias: Minor_AADT_YEAR, length: 4 )
• Minor_Highway_Group ( type: esriFieldTypeString, alias: Minor_Highway_Group, length: 1 , Coded Values: [D: D - Divided Highway] , [L: L - Independent Alignment - Left] , [R: R - Independent Alignment - Right] , ...2 more... )
• Minor_Signal_Arm_Ind ( type: esriFieldTypeSmallInteger, alias: Minor_Signal_Arm_Ind , Coded Values: [0: 0 - No] , [1: 1 - Yes] )
• Minor_Left_Channel ( type: esriFieldTypeString, alias: Minor_Left_Channel, length: 1 , Coded Values: [C: C- Curbed Median Left Turn Channelization] , [N: N- No Left Turn Channelization] , [P: P- Painted Left Turn Channelization] , ...2 more... )
• Minor_Right_Channel_Ind ( type: esriFieldTypeString, alias: Minor_Right_Channel_Ind, length: 1 )
• Minor_N_Distance ( type: esriFieldTypeInteger, alias: Minor_N_Distance )
• Minor_PMRouteID ( type: esriFieldTypeString, alias: Minor_PMRouteID, length: 75 )
• Minor_RouteNum ( type: esriFieldTypeString, alias: Minor_RouteNum, length: 4 )
• Minor_RouteSuffix ( type: esriFieldTypeString, alias: Minor_RouteSuffix, length: 1 )
• Minor_Alignment ( type: esriFieldTypeString, alias: Minor_Alignment, length: 1 )
• Minor_PMPrefix ( type: esriFieldTypeString, alias: Minor_PMPrefix, length: 1 )
• Minor_PMSuffix ( type: esriFieldTypeString, alias: Minor_PMSuffix, length: 1 )
• Minor_PMMeasure ( type: esriFieldTypeDouble, alias: Minor_PMMeasure )
• InventoryItemStartDate ( type: esriFieldTypeDate, alias: InventoryItemStartDate, length: 8 )
• InventoryItemEndDate ( type: esriFieldTypeDate, alias: InventoryItemEndDate, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
